HT912 Hydraulic Trencher
The Red Roo HT912 is an all hydraulic compact trencher that is perfect for the installation of irrigation, sprinkler and electrical systems.
Key Features
- Self Propelled, forward, neutral and reverse
- Ideal for irrigation installation, lawn sprinkler systems, communication cables
- All Hydraulic for greater reliability low maintenance
BEST-SELLING SMALL TRENCHER IN AUSTRALIA & NEW ZEALAND
The Red Roo HT912 is an all-hydraulic compact trencher that is perfect for the installation of irrigation, sprinkler, and electrical systems.
It is powered by a 9hp Honda OHV engine.
The HT912 is available with 300mm (12"), 450mm (18") or 600mm (24") boom.
This model has been the best-selling compact trencher to the demanding hire and rental industry for over twenty years.
The HT912 is the best-selling trencher in Australia and New Zealand.
HT912 FOR IRRIGATION, SPRINKLER AND ELECTRICAL SYSTEMS
Engine | |
|---|---|
| Engine Type | HONDA 9hp |
General | |
| Trench Depth | 600mm ( 24") |
| Trench Width | 100mm (4") |
| Boom Travel Up | 5¼ |
| Boom Travel Down | 59¼ |
| Front Wheel to Handlebar | 889mm |
| Boom End to Handlebar | 2060mm (81") |
| Wheel Width | 711mm (28") |
| Handlebar Width | 736mm (29") |
| Total Height | 1100mm (43") |
| Wheel Base | 762mm (30") |
| Weight | 280kgs (620lbs) |
| Ground Speed Forward | 40mpm (132fpm) |
| Ground Speed Reverse | 17mpm (58fpm) |
| Digging Chain Speed | 70mpm (227fpm) |
Features | |
|---|---|
| Self Propelled, forward, neutral and reverse | |
| Ideal for irrigation installation, lawn sprinkler systems, communication cables | |
| All Hydraulic for greater reliability low maintenance | |
| Compact and light weight for easy operation | |
| Safety clutch stops wheels and chain immediately | |
| Chain reverse to dislodge rocks and debris | |
| Wheel locks allow unit to be freewheeled | |
HT912 Hydraulic Self Propelled Trencher 9hp Honda Engine Maximum Depth 600mm Maximum Width 100mm
HT912 Mini Irrigation Trencher for Hire or Sale
HT912 Hydraulic Trencher being demonstrated by KennardsHT912 Hydraulic Trencher
PADDOCK TRENCHER
Made in China.
Wooden box distribution model.
Benefits and features are very similar to all other pedestrian trenchers imported from China.
No self-propulsion.
Chain and sprocket drive system.
Not designed for Australian conditions, which, due to our ground conditions, could be the most difficult in the world.
Consider hiring or renting a Red Roo Trencher from your local Hire and Rental Store.
MADE IN CHINA
WOODEN BOX DISTRIBUTION MODEL
BENEFITS AND FEATURES ARE IDENTICAL TO ALL OTHER CHINESE IMPORTED MACHINES
NO SELF-PROPEL
CHAIN AND SPROCKET DRIVE SYSTEM
NOT DESIGNED FOR EXTREMELY DIFFICULT AUSTRALIAN CONDITIONS
HIRE A RED ROO TRENCHER FROM YOUR LOCAL HIRE AND RENTAL STORE
A MUCH BETTER OPTION THAN PURCHASING A PADDOCK
Shipping details for the HT912 trencher are shown below:
HT912 Trencher (Shipping Dimensions Assembled Banded To Pallet)
Width: 750mm
Length: 2400mm
Height: 1230mm
Weight: 300kgs (Shipping Weight)
